"Like other Quicksilver products, the solidity of presentation, that is, dimensionality, imaging, and soundstage is quite remarkable." Paul Seydor, the absolute sound, October 2002.
Released in 2015, the latest version of the Quicksilver Line Stage offers a simplified switching and signal path. With almost 10 times the output current capability of the previous Line Stage, will drive any amplifier input impedance and interconnect cable with ease. The new Linestage embodies the Quicksilver philosophy "simplicity is the essence of good engineering".
Specifications:
| Bandwidth |
0.1 Hz to 100 kHz +0,-3db |
| IM Distortion |
less than 0.08% at 1v output |
| Harmonic Distortion |
less than 0.08% at 1v output from 10 Hz to 40 kHz |
| Gain |
18dB |
| Input Impedance |
100 Kohm, 20 Hz-20 kHz |
| Output Impedance |
100 ohms, 20 Hz-20 kHz |
| Output Polarity |
Inverted |
| Maximum Input |
30 volts RMS, 20 Hz-20 kHz |
| Maximum Output |
0 volts RMS, 20 Hz-20 kHz |
| Noise |
20 microvolts RMS residual IHF weighted noise output with gain control at minimum |
| Tube Complement |
2-12AT7 |
| Dimensions |
3″H, 9 1/2″D, 15″W |
| Front Panel |
3 1/4″H, 17″W |
| Weight |
12 lbs. |
| U.S. Warranty |
3 years parts and labor
Tubes 90 days |
|
