"Like other Quicksilver products, the solidity of presentation, that is, dimensionality, imaging, and sound staging is quite remarkable." Paul Seydor, the absolute sound, October 2002.
Improved soundstage width and depth and higher resolution are changes to the Remote control Linestage Preamp for 2012. In addition, a newly designed audio choke increases power and dynamics. The internal shielded cable has been eliminated, output impedance has been lowered and the power supply filtering and capacitance have been increased. A precision motorized Alps attenuator is still the best sounding volume control and video pass-through is available on request.
Specifications:
Bandwidth: 0.1 Hz to 80 KHz
IM Distortion: less than 0.02% at 1v output
Harmonic Distortionless: than 0.02% at 1v output from 10 Hz to 40 KHz
Gain: 18 db
Input Impedance: 50 Kohms, 20 Hz-20 KHz
Output Impedance: 600 ohms, 20 Hz-20 KHz
Output polarity: + 180 degrees
Maximum Input: 30 volts RMS, 20 Hz-20 KHz
Maximum Output: 60 volts RMS, 20 Hz-20 KHz
Noise: 20 microvolts RMS residual IHF weighted noise output with gain control at minimum
Tube Complement: 2-6DJ8, Note:6N1P or 6AQ8 tubes may be substituted
Dimensions: 3"Hx9.5"Dx15"W
Front Panel: 3.25"Hx17" W
Weight 12 lbs.
U.S. Warranty 3 years parts and labor
Tubes 90 days
|
